Alternative equivalent for Infineon IR2103S | Slkor SL2103 Gate Driver lCs

Our advantages

Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China.  As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.

Slkor alternative equivalents to Infineon.

Description

The SL2103 is a high voltage, high speed power MOSFET and IGBT drivers with dependent high and low-side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3 V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high-side configuration which operates up to 600 V.

Features

● Floating channel designed for bootstrap operation

● Fully operational to +600 V

● Tolerant to negative transient voltage, dV/dt immune

● Gate drive supply range from 10 V to 20 V

● Undervoltage lockout

● 3.3 V, 5 V, and 15 V logic compatible

● Cross-conduction prevention logic

● Matched propagation delay for both channels

● Internal set deadtime

● High-side output in phase with HIN input

● Low-side output out of phase with LIN input

● RoHS compliant

● SOP-8 package

Application
● Switching mode power supplies

● DC-to-DC converters

● Motor Control, solar power

● Gate drive for emerging wide band-gap power devices such as GaN
