Description

lThis Power MOSFET is produced using advanced TRENCH technology. This advanced technology has been especially tailored to minimize conduction loss, provide superior switching performance, and with stand high energy pulse in the avalanche and commutation mode.

Features

lVDS=30V，ID=160A

lRDS（ON）TYP=1.5mΩ@VGS=10V

lRDS（ON）TYP=2.2mΩ@VGS=4.5V

lVery Low On-resistance RDS(ON)

lLow Crss

lFast switching

l100% avalanche tested

lImproved dv/dt capability

Application

lPower Management

lPWM Application

lLoad Switch
