Description
lThe SL9013 Series are highly precise,low noise,positive voltage LDO regulatorsmanufactured using CMOS processes.The SL9013 performance is optimized forbattery-powered systems to deliver ultra low noise and low quiescent current.Regulator ground current increases only slightly in dropout,further prolonging the battery life.The SL9013 Series also works with low-ESR ceramic capacitors,reducing the amount of board space necessary for power applications,critical inhand-held wireless devices.The SL9013 Series consumes less than 1μA in shutdown mode and has fast tum-on time less than 50s.The other features include ultra low dropout voltage,high output accuracy,current limiting protection,and highripple rejection ratio.
Features
lUlra Low Noise for RF Application
lUltra Fast Response in Line/Load Transient
lLow Power Consumption:70uA(Typ.)
lPSRR=75dB@1KHz
lMaximum Output Current:500mA
lLow Dropout:100mV @100mA at Vout=3.3V
lOperating Voltage Ranges:2V to 6.5V
lOver Temperature and Current Limiting Protection
lThermal Shutdown Protection
Applications
lBaltery-Powered Equipment
lCDMA/GSM Cellular Handsets
lAudio/Video Equipment
